2015.01.14 6
INDOOR UNIT
WALL MOUNTED
ASU18RLF
ASU24RLF
39-9/32 inch 998 mm
8-31/32 inch
228 mm
12-19/32 inch
320 mm
INDOOR UNIT
COMPACT WALL MOUNTED
ASU7RLF1
ASU9RLF1
ASU12RLF1
33-1/16 inch 840 mm
10-9/16inch
268 mm
15.8 to 16.7
8 inch
203 mm
Drain hose
Diameter
Outside
Inside : 13.8 mm
23-5/8 inch 600 mm
