Fujitsu AO G12KATA Series Service Manual

¢ Medium static pressure duct type
• Rotation number range of compressor
Unit: rps
Model name Outdoor temperature zone Operating rotation number
ARXG22KMLB
X zone 54
J zone 54
Y zone 0
• Compressor control based on room temperature
Ts+0.5°C
Ts -1.5°C
Ts-0.5°C
Ts+1.5°C
X zone
J zone
Y zone
Room temperature drops
Room temperature rises
Ts: Set temperature
¢ Wall mounted type (For KGTB and KGTE)
• Rotation number range of compressor
Unit: rps
Model name Outdoor temperature zone Operating rotation number
ASHG07KGTB
ASHG09KGTB
X zone 54
ASHG12KGTB
ASHG14KGTB
ASHG07KGTE
J zone 54
ASHG09KGTE
ASHG12KGTE
ASHG14KGTE
Y zone 0
• Compressor control based on room temperature
Ts+0.5°C
Ts -1.5°C
Ts-0.5°C
Ts+1.5°C
X zone
J zone
Y zone
Room temperature drops
Room temperature rises
Ts: Set temperature
1-3. Dry operation
- (04-12) - 1. Rotation number control of compressor
CONTROL AND FUNCTIONS CONTROL AND FUNCTIONS
