1-2. Outdoor unit
¢
Specifications
Type Inverter heat pump
Model name AOHG14KBTA2 AOHG18KBTA2
Power source 230 V 50 Hz
Available voltage range 198—264V
Standard combination of indoor unit
Wall mounted
ASHG07KGTB ×2
Wall mounted
ASHG09KGTB ×2
Capacity
Cooling
Rated
kW 4.0 5.0
Btu/h 13,600 17,100
Min.—Max.
kW 1.4—4.6 1.7—5.8
Btu/h 4,700—15,700 5,800—19,800
Heating
Rated
kW 4.4 5.6
Btu/h 15,000 19,100
Min.—Max.
kW 1.1—5.5 1.8—6.6
Btu/h 3,700—18,800 6,100—22,500
Input power
Cooling
Rated
kW
0.97 1.24
Max. 1.20 1.55
Heating
Rated 0.95 1.22
Max. 1.65 1.80
Current
Cooling Rated
A
4.7 5.6
Heating Rated 4.7 5.6
EER Cooling
kW/kW
4.12 4.03
COP Heating 4.63 4.59
Starting current A 4.7 5.6
Maximum operating current *
1
A 10.9 11.6
Fan
Type × Q'ty Propeller × 1
Airflow rate
Cooling
m
3
/h
1,670 1,960
Heating 1,670 2,020
Motor output W 23 49
Sound pressure level *
2
Cooling
dB (A)
47 47
Heating 49 50
Heat exchanger
Dimension (H x W x D)
mm
504 × 881 × 18.19
504 × 851 × 18.19
588 × 881 × 18.19
588 × 851 × 18.19
Fin pitch 1.3
Rows × Stages
Main1: 1 × 24
Main2: 1 × 24
Pipe type (Material) Copper tube
Fin type (Material) Aluminum
Compressor
Type × Quantity DC rotary × 1 DC twin rotary × 2
Motor output W 900 900
Refrigerant
Type R32 (675)
Charge g 900 1,020
Refrigerant oil
Type RB68A FW68S
Amount
cm
3
340 350
Enclosure
Material Steel sheet
Color
Beige
(Approximate color of Munsell 10YR 7.5/1.0 NN)
Dimensions
(H x W x D)
Net
mm
542 × 799 × 290 632 × 799 × 290
Gross 602 × 940 × 375 692 × 940 × 375
Weight
Net
kg
33 37
Gross 37 42
Connection pipe
Size
Liquid
mm (in)
Ø6.35 (Ø1/4) × 2
Gas Ø9.52 (Ø3/8) × 2
Method Flare
Pre-charge length (Total)
m
20
Maximum length (Total) 30
Maximum length (Each) 20
Minimum length (Total) 5
Minimum length (Each) 2.5
Maximum height difference between outdoor unit
and each indoor units.
15
Maximum height difference between indoor units. 10
Operation range
Cooling
°C
-10 to 46
Heating -15 to 24
NOTES:
• Specifications are based on the following conditions:
– Power source of specifications: 230 V
– Pipe length: 5 m, Height difference: 0 m [Outdoor unit—Indoor unit]
– Cooling: Indoor temperature of 27.0 °CDB/19.0 °CWB, and outdoor temperature of 35 °CDB/24.0 °CWB.
– Heating: Indoor temperature of 20.0 °CDB/15.0 °CWB, and outdoor temperature of 7.0 °CDB/6.0 °CWB.
• *1: Maximum operating current is the total current of the indoor unit and the outdoor unit.
• *2: Sound pressure level
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
• For other combination, refer to the combination table.
• The protective function might work when using it outside the operation range.
1-2. Outdoor unit
- (01-12) - 1. Specifications
