5-4. Indoor unit fan motor
¢ Models: AUXG07KVLA, AUXG09KVLA, AUXG12KVLA, and
AUXG14KVLA
Check point 1. Check rotation of fan
Rotate the fan by hand when operation is off.
(Check if fan is caught, dropped off or locked motor)
→ If fan or bearing is abnormal, replace it.
Check point 2. Check resistance of indoor fan motor
Refer to below. Circuit-test “Vm” and “GND” terminal
NOTE: Vm: DC voltage, GND: Earth terminal
→ If they are short-circuited (below 300 kΩ), replace indoor fan motor and controller PCB.
Pin number
(wire color)
Terminal function
(symbol)
1 (Red) DC voltage (Vm)
2 No function
3 (Black) Ground terminal (GND)
4 (White) Control voltage (Vcc)
5 No function
6 No function
7 (Yellow) Speed command (Vsp)
8 (Blue) Feed back (FG)
5-4. Indoor unit fan motor - (03-83) - 5. Service parts information
