2-3. Maintenance space requirement
For future maintenance and service access, provide sufficient maintenance space.
NOTE: Do not place any wiring or illumination in the maintenance space, as they will impede ser-
vice.
¢
Models: ARXG24KMLA, ARXG30KMLA, ARXG36KMLA, and
ARXG45KMLA
Unit: mm
• Provide a service access for maintenance purposes.
Maintenance hole
Control box
300
500
500
100
• The service access necessary for fan units and filter maintenance.
Maintenance hole
Intake panel
300
1,550
500
100
Control box
• When using a square duct
P174
×
6 = 1,044
Φ
3.2
46
23
18
219
109
• Bottom air intake hole
108
1,015
16 240
- 6 -
2-3. Maintenance space requirement
2. Dimensions
DUCT TYPE ARXG24-45KMLA DUCT TYPE ARXG24-45KMLA
