Model: AOYG45KATA
Fan speed is defined by outdoor temperature and compressor frequency.
Unit: rpm
Fan step Cooling or dry Heating
13 970 —
12 900 —
11 830 —
10 760 970
9 690 880
8 620 800
7 550 720
6 480 630
5 420 520
4 360 440
3 300 360
2 240 270
1 200 200
S-HIGH — 990
• When the compressor frequency increases, the outdoor fan speed also changes to the higher
speed.
• When the compressor frequency decreases, the outdoor fan speed also changes to the lower
speed.
NOTE: After defrost control on the heating mode, the fan speed is kept higher regardless of the
compressor frequency.
Fan speed after defrost control: 990 rpm
3-2. Outdoor fan control - (04-16) - 3. Fan control
