4. Louver control
4-1. Individual louver control
To independently can be set the airflow pattern of each louver as follows:
This function is given priority to overall louver control. But this function is release during the following
operation.
Cold air prevention control
Monitor mode on the auto change over operation
Defrost operation
The air direction range will change as follows:
Use the wired remote controller to set this function. This function is only available by 2 wire remote
controller.
NOTE:
When the 2 wire remote controller is disconnected, clear the individual setting. Otherwise,
this setting can’t change.
4-2. All louver control
All louver operation
When the mode is selected, the standard louver position of the each mode is set.
model name Operation mode Standard Position
AUXG30KRLB
AUXG36KRLB
Cooling 2
Dry 2
Heating 4
Monitor 2
AUXG45KRLB
AUXG54KRLB
Cooling 2
Dry 2
Heating 3
Monitor 2
NOTES:
Setting of the wireless remote controller is not displayed on the wired remote controller.
The setting louver of the individual control function cannot be controlled.
4-1. Individual louver control
- (04-18) - 4. Louver control
CONTROL AND
FUNCTIONS
CONTROL AND
FUNCTIONS
