REFRIGERANT
SYSTEM DIAGRAM
Strainer
Strainer
Service port
Pressure sensor
3-way valve 3-way valve
Muffler
Muffler
Pressure switch
Check valve
4-Way valve
Expansion valve
Heat exchanger
(Indoor unit)
Heat exchanger
(Outdoor unit)
Sub-accumulator
Compressor
Cooling flow
Heating flow
Refrigerant pipe diameter
Liquid : 1/4" (6.35 mm)
Gas : 5/8" (15.88 mm)
32012.08.08
