Fujitsu AOU12RL2

24
22
21
28
INDOOR UNIT
Control box
12
26
Terminal 9900720001
Main PCB (09) 9709170076
25
Earth Terminal 9332553024
21
Control Box
9332554007
22
Cover Shield
9332542011
23 Box Shield Assy 9332561005
24
Main PCB (12) 970917008324
28 Room Thermistor Holder 9316895003
Ref. Description Part number
27
29 Thermistor Assy 9900714017
Display Assy 9709173015
27
29
23
25
26
2012.10.30
