INDOOR UNIT
Front panel
2011.12.28
14
15
Air Filter
9318909005
12
Front Panel
9318876000
16
Display Plate Holder L
9318894004
14
Front Panel Cover T
17
9318895001
18
Display Plate R
9318893007
Display Plate Holder R
19
9318900002
22
Pyroelectric Sensor Assy
9319346007
20
Grille Stay
9318899009
21
Grille Clamper B
9316951006
Arm Cover
9318883008
13
Intake Grille Assy
9319351186
11
Front Panel Total Assy
9319348209
Ref.
Description
Part number
22
14
16
Table of Contents
Table of Contents
1
Wall Mounted Type
1
Indoor Unit
1
Specifications
2
Dimensions
3
Refrigerant System Diagram
4
Circuit Diagram
5
Indoor Pcb Circuit Diagram
6
Outdoor Pcb Circuit Diagram
10
Indoor Unit Remote Control
12
Error Detection
12
Parts (Indoor Unit)
14
Parts (Outdoor Unit)
19
Accessories
22
