INDOOR UNIT
Control box
12
2014.12.12
Terminal 990072002524
Control Box22
Cover shield
21 9318757033Control Cover
9380996026
Main PCB 970962213123
26
Room Thermistor Holder
9379930000
Ref. Description Part number
25
27 Thermistor Assy 9900627003
Display Assy 9709642023
23
22
21
26
25
24
27
