INDOOR UNIT
Casing assy
16
Fan Guard 9320458003
79
80
76
Drain Hose Assy 9316904019
Pipe Bracket 931874301278
Drain Cap 9316177017
71
Casing Cover B 9318862003
74
Casing Cover F 9318864007
Casing Cover L 9318830002
Casing Cover R 931883100975
R and L Louver Assy
9319229027
Casing 9318840018
77
72
73
Ref. Description Part number
