OUTDOOR UNIT
2014.12.12 18
30 Outdoor Thermistor 9900544041
26 ACTPM 9707592016
29 Terminal 6P 9900016081
27 Heatsink 9318614015
28 Choke Coil 9900223014
Capacitor PCB 9708514017
24
Main PCB (RLS3)
9709217122
25
31 Thermistor Assy 9900648008
22
Filter PCB (RLS3)
24 9708764047Filter PCB (RLS3H)
9708511702
Main PCB (RLS3H)22 9708511672
Terminal Cover Assy
21 9317898027
23 Transistor PCB 9708646077
Ref. Description Part number
28
25
29
24
27
22
23
26
30
31
21
