REPLACEMENT PARTS
09-07
PROCESS
1
1
2
3
4
Fixing of Thermistor lead and motor lead.
THERMISTOR ASSY (SUC/DIS)
THERMISTOR (OUT TEMP)
MOTOR LEAD
COIL(EXP VLV)
0~5mm
200~230mm
10 10mm
E-E
B-B
190~220mm
160~190mm
120~140mm
BB
AA
1
2
2
2
4
4
4
3
3
3
1
1
1
