Thermistor (Heat exchanger temp.)
Coil (Expansion valve)&
Expansion valve
Check valve
Pressure SW
AOU18
2-way valve (Liquid)
AOU24/ 36
3-way valve (Liquid)
3-way valve
(Gas)
03-02
Thermo Holder&
Thermistor (Outdoor Temp.)
