Fujitsu AOU18RLX - Page 72

As shown in Fig.8, connect wires.
As shown in Fig.9, connect wires.
03-13
Fig. 8
Fig. 9
CN1 (White)CN34 (Yellow)
Through this hole.
W21 (Orange)
W22 (Orange)
TM102 (White line)TM101 (Black line)
PTC Thermistor
For AOU36RLX
