Fujitsu AOU18RLX - Page 5

1-3/16" (30mm)
37" (940mm)
37" (940mm)
29-17/32" (750mm)
29-17/32" (750mm)
11-5/8" (296mm)
2-3/8" (60mm)
Drain pipe (I.D.32mm)
11-3/4"
(298.5mm)
11-7/32" (250mm)
12"
(305.5mm)
9-25/32"
(248.5mm)
3-5/8" (92mm)
2-3/8" (60mm)
12"
(305.5mm)
11-3/4" (298.5mm)
9-25/32"
(248.5mm)
5" (127mm)
11-7/32" (285mm)
Drain pipe(I.D.32mm)
Unit : inch (mm)
INDOOR UNIT
Models :
AUU36RCLX, AUU42RCLX
2005.12.21 4
