Fujitsu AOU18RLXFW1

OUTDOOR UNIT AOU18RLXFW1 AOU24RLXFW1
2016.01.12
17
27
30
26
25
29
28
29 ACTPM 9707592016
30 Heatsink 9378530010
25 PTC Thermistor (AOU24) 9704265012
26 Capacitor PCB (AOU18) 9709894033
26 Capacitor PCB (AOU24) 9709894040
28 Transistor PCB (AOU24) 9708512181
28 Transistor PCB (AOU18) 9708512174
27 Choke Coil 9900223014
Valve plate
21 Discharge Thermistor 9900461003
22 Outdoor Thermistor 9900463007
23 Compressor Thermistor 9900466015
24
Heat Exchanger Thermistor
9900514013
Ref. Part numberDescription
22
23
24
21
Connector : Blue
Connector : Orange
Connector : Green
Connector : Red
