DIMENSIONS
Unit : inch (mm)
Drain pipe diameter
Inside : 5/8 inch (16 mm)
Outside : 1-3/32 inch (28 mm)
Liquid pipe diameter : 3/8 inch (9.52 mm)
Gas pipe diameter : 5/8 inch (15.88 mm)
INDOOR UNIT
39-1/4" (998) 9" (228)
12-5/8"
(320)
2010.02.26 2
