Fujitsu AOU24RLXFW Design & Technical Manual

- (01 - 11) -
WALL MOUNTED TYPE ASU18-24RLF WALL MOUNTED TYPE ASU18-24RLF
HEATING CAPACITY6-2.
MODEL

: ASU18RLF
AFR 541
Indoor temperature
°FDB 60 65 70 72 75
Outdoor temperature
°FDB °FWB TC IP TC IP TC IP TC IP TC IP
5 3 18.8 2.50 18.4 2.55 17.9 2.60 17. 5 2.65 17.0 2.70
14 12 21.3 2.67 20.8 2.73 20.3 2.78 19.8 2.84 19.3 2.89
23 19 24.7 2.86 24.1 2.92 23.5 2.98 22.9 3.04 22.3 3.10
32 28 27.5 2.87 26.8 2.93 26.2 2.99 25.5 3.05 24.9 3.11
41 37 29.3 2.84 28.6 2.90 27.9 2.96 27.2 3.02 26.5 3.08
47 43 30.5 2.87 29.7 2.93 29.0 2.99 28.3 3.05 27.6 3.11
50 47 31.0 2.85 30.3 2.91 29.5 2.97 28.8 3.03 28.0 3.09
59 50 29.2 2.48 28.5 2.53 27.8 2.58 27.2 2.63 26.5 2.68
AFR : Air ow rate (CFM)
TC : Total capacity (kBTU)
IP : Input Power (kW)
AFR 15.3
Indoor temperature
°CDB 15.6 18.3 21.1 21.2 23.9
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP TC IP
-15 -16 5.52 2.50 5.39 2.55 5.26 2.60 5.13 2.65 5.00 2.70
-10 -11 6.24 2.67 6.09 2.73 5.95 2.78 5.80 2.84 5.65 2.89
-5 -7 7.24 2.86 7.07 2.92 6.89 2.98 6.72 3.04 6.55 3.10
0 -2 8.05 2.87 7.86 2.93 7.67 2.99 7.48 3.05 7.29 3.11
5 3 8.59 2.84 8.38 2.90 8.18 2.96 7.98 3.02 7.77 3.08
7 6 8.93 2.87 8.71 2.93 8.50 2.99 8.29 3.05 8.08 3.11
10 8 9.08 2.85 8.87 2.91 8.65 2.97 8.43 3.03 8.22 3.09
15 10 8.57 2.48 8.37 2.53 8.16 2.58 7.96 2.63 7.75 2.68
AFR : Air ow rate (m
3
/min)
TC : Total capacity (kW)
IP : Input Power (kW)
MODEL

: ASU24RLF
AFR 677
Indoor temperature
°FDB 60 65 70 72 75
Outdoor temperature
°FDB °FWB TC IP TC IP TC IP TC IP TC IP
5 3 25.3 3.30 24.7 3.37 24.1 3.44 23.5 3.51 22.9 3.58
14 12 27.5 3.32 26.9 3.39 26.2 3.46 25.6 3.53 24.9 3.60
23 19 30.8 3.27 30.0 3.34 29.3 3.41 28.6 3.48 27.8 3.55
32 28 33.8 3.27 33.0 3.33 32.2 3.40 31.4 3.47 30.6 3.54
41 37 36.9 3.29 36.0 3.36 35.1 3.43 34.3 3.49 33.4 3.56
47 43 38.0 3.25 37.1 3.32 36.2 3.38 35.3 3.45 34.4 3.52
50 47 38.7 3.24 37.8 3.31 36.9 3.37 35.9 3.44 35.0 3.51
59 50 36.9 2.85 36.0 2.91 35.1 2.97 34.2 3.03 33.4 3.09
AFR : Air ow rate (CFM)
TC : Total capacity (kBTU)
IP : Input Power (kW)
AFR 19.2
Indoor temperature
°CDB 15.6 18.3 21.1 21.2 23.9
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP TC IP
-15 -16 7.40 3.30 7.23 3.37 7.05 3.44 6.87 3.51 6.70 3.58
-10 -11 8.07 3.32 7.88 3.39 7.69 3.46 7.50 3.53 7.30 3.60
-5 -7 9.02 3.27 8.81 3.34 8.59 3.41 8.38 3.48 8.16 3.55
0 -2 9.91 3.27 9.67 3.33 9.44 3.40 9.20 3.47 8.97 3.54
5 3 10.81 3.29 10.55 3.36 10.30 3.43 10.04 3.49 9.78 3.56
7 6 11.13 3.25 10.87 3.32 10.60 3.38 10.34 3.45 10.07 3.52
10 8 11.34 3.24 11.07 3.31 10.80 3.37 10.53 3.44 10.26 3.51
15 10 10.80 2.85 10.55 2.91 10.29 2.97 10.03 3.03 9.78 3.09
AFR : Air ow rate (m
3
/min)
TC : Total capacity (kW)
IP : Input Power (kW)
