10. Electrical characteristics
Model name AOU9RL2 AOU12RL2
Power supply
Voltage V 115~
Frequency Hz 60
MCA *
1
A 13.5 15.0
Starting current A 7.5 11.0
Wiring spec. *
2
MAX. CKT. BKR *
3
A 15 20
Power cable AWG 14
Connection
cable *
4
Size AWG 14
Limited wiring
length
ft (m) 69 (21)
NOTES:
• *
1
: Minimum Circuit Ampacity (Calculation based on UL1995)
• *
2
: Selected sample based on Japan Electrotechnical Standards and Codes Committee E0005.
As the regulations of wire size and circuit breaker differ in each country or region, select appro-
priate devices complied to the regional standard.
• *
3
: Maximum Circuit Breaker
• *
4
: Limit voltage drop to less than 2%. If voltage drop is 2% or more, increase cable conductor
size.
- 39 -
