Fujitsu AOUH12LUAS1 Design & Technical Manual

¢ Model: ADUH12LUAS1
AFR CFM 383
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
14 10.36 9.54 0.33 11.54 9.59 0.33 11.93 10.43 0.33 13.11 11.30 0.34 13.90 11.25 0.34 14.68 11.99 0.34
23 10.28 9.44 0.38 11.45 9.50 0.38 11.84 10.33 0.39 13.01 11.19 0.39 13.79 11.15 0.40 14.57 11.87 0.40
32 10.20 9.36 0.41 11.36 9.42 0.41 11.75 10.24 0.42 12.91 11.09 0.42 13.68 11.05 0.43 14.46 11.77 0.43
41 10.12 9.30 0.44 11.27 9.36 0.44 11.66 10.17 0.45 12.81 11.02 0.45 13.58 10.98 0.46 14.35 11.69 0.46
50 10.04 9.22 0.45 11.18 9.27 0.45 11.57 10.08 0.46 12.71 10.92 0.46 13.47 10.88 0.47 14.24 11.59 0.47
59 9.96 9.16 0.46 11.10 9.21 0.47 11.48 10.01 0.47 12.61 10.85 0.47 13.37 10.81 0.48 14.12 11.51 0.48
67 11.23 10.34 0.64 12.51 10.40 0.65 12.94 11.31 0.66 14.22 12.25 0.67 15.07 12.20 0.67 15.93 13.00 0.68
77 10.69 9.82 0.73 11.91 9.87 0.75 12.31 10.73 0.75 13.53 11.63 0.76 14.34 11.58 0.77 15.15 12.34 0.78
87 10.10 9.27 0.82 11.25 9.32 0.83 11.63 10.13 0.83 12.78 10.98 0.84 13.55 10.94 0.85 14.31 11.65 0.86
95 9.48 8.71 0.91 10.56 8.76 0.92 10.92 9.53 0.93 12.00 10.32 0.94 12.72 10.28 0.95 13.44 10.95 0.96
104 8.00 7.76 0.77 8.91 7.81 0.78 9.22 8.49 0.79 10.13 9.20 0.80 10.74 9.16 0.81 11.35 9.76 0.82
115 7.38 7.21 0.77 8.22 7.25 0.78 8.50 7.88 0.79 9.34 8.54 0.80 9.90 8.51 0.81 10.46 9.06 0.82
AFR
m
3
/h
650
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.2 19.4 21.7 22.8
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW
-10.0 3.04 2.80 0.23 3.38 2.81 0.23 3.50 3.06 0.23 3.84 3.31 0.23 4.07 3.30 0.24 4.30 3.51 0.24
-5.0 3.01 2.77 0.26 3.36 2.79 0.26 3.47 3.03 0.26 3.81 3.28 0.27 4.04 3.27 0.27 4.27 3.48 0.27
0.0 2.99 2.74 0.27 3.33 2.76 0.28 3.44 3.00 0.28 3.78 3.25 0.28 4.01 3.24 0.28 4.24 3.45 0.29
5.0 2.97 2.73 0.27 3.30 2.74 0.28 3.42 2.98 0.28 3.76 3.23 0.28 3.98 3.22 0.28 4.21 3.43 0.29
10.0 2.94 2.70 0.27 3.28 2.72 0.27 3.39 2.95 0.27 3.73 3.20 0.28 3.95 3.19 0.28 4.17 3.40 0.28
15.0 2.92 2.68 0.28 3.25 2.70 0.28 3.36 2.94 0.28 3.70 3.18 0.29 3.92 3.17 0.29 4.14 3.37 0.29
19.4 3.29 3.03 0.45 3.67 3.05 0.46 3.79 3.31 0.46 4.17 3.59 0.47 4.42 3.58 0.47 4.67 3.81 0.48
25.0 3.13 2.88 0.51 3.49 2.89 0.52 3.61 3.15 0.52 3.97 3.41 0.53 4.20 3.40 0.53 4.44 3.62 0.54
30.6 2.96 2.72 0.58 3.30 2.73 0.59 3.41 2.97 0.60 3.75 3.22 0.61 3.97 3.21 0.61 4.20 3.42 0.62
35.0 2.78 2.55 0.64 3.10 2.57 0.65 3.20 2.79 0.65 3.52 3.03 0.66 3.73 3.01 0.67 3.94 3.21 0.67
40.0 2.35 2.28 0.60 2.61 2.29 0.61 2.70 2.49 0.62 2.97 2.70 0.63 3.15 2.69 0.63 3.33 2.86 0.64
46.0 2.16 2.11 0.47 2.41 2.13 0.48 2.49 2.31 0.48 2.74 2.50 0.49 2.90 2.49 0.49 3.07 2.66 0.50
¢ Model: ADUH18LUAS1
AFR CFM 553
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
14 15.00 12.29 0.47 16.71 12.36 0.48 17.28 13.44 0.48 18.99 14.56 0.49 20.13 14.50 0.49 21.27 15.45 0.50
23 14.77 12.07 0.51 16.45 12.14 0.52 17.01 13.20 0.52 18.69 14.30 0.53 19.81 14.25 0.53 20.94 15.18 0.54
32 14.53 11.90 0.53 16.19 11.97 0.54 16.74 13.02 0.54 18.40 14.10 0.55 19.50 14.05 0.56 20.60 14.96 0.56
41 14.30 11.72 0.53 15.93 11.78 0.54 16.47 12.81 0.54 18.10 13.88 0.55 19.19 13.82 0.56 20.27 14.73 0.56
50 14.07 11.52 0.55 15.67 11.59 0.56 16.20 12.59 0.56 17.81 13.65 0.57 18.88 13.59 0.57 19.94 14.48 0.58
59 13.84 11.31 0.58 15.41 11.38 0.59 15.94 12.37 0.60 17.51 13.40 0.61 18.56 13.35 0.61 19.61 14.22 0.62
67 15.89 13.02 0.95 17.70 13.10 0.97 18.31 14.24 0.97 20.12 15.43 0.99 21.33 15.37 1.00 22.53 16.37 1.01
77 15.16 12.39 1.07 16.88 12.46 1.08 17.46 13.55 1.09 19.19 14.68 1.11 20.34 14.62 1.12 21.49 15.57 1.13
87 14.37 11.76 1.21 16.00 11.83 1.23 16.55 12.87 1.23 18.18 13.94 1.25 19.28 13.88 1.26 20.37 14.79 1.28
95 13.51 11.07 1.32 15.05 11.14 1.34 15.56 12.11 1.35 17.10 13.12 1.37 18.13 13.06 1.38 19.15 13.92 1.40
104 11.86 9.70 1.30 13.21 9.76 1.32 13.66 10.61 1.32 15.01 11.50 1.34 15.91 11.45 1.36 16.81 12.20 1.37
115 9.95 8.83 1.28 11.09 8.88 1.30 11.47 9.66 1.31 12.60 10.46 1.33 13.36 10.42 1.34 14.11 11.10 1.36
AFR
m
3
/h
940
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.2 19.4 21.7 22.8
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW
-10.0 4.40 3.60 0.23 4.90 3.62 0.23 5.07 3.94 0.23 5.57 4.27 0.23 5.90 4.25 0.24 6.23 4.53 0.24
-5.0 4.33 3.54 0.26 4.82 3.56 0.26 4.99 3.87 0.26 5.48 4.19 0.27 5.81 4.18 0.27 6.14 4.45 0.27
0.0 4.26 3.49 0.27 4.75 3.51 0.28 4.91 3.82 0.28 5.39 4.13 0.28 5.72 4.12 0.28 6.04 4.39 0.29
5.0 4.19 3.43 0.27 4.67 3.45 0.28 4.83 3.76 0.28 5.31 4.07 0.28 5.63 4.05 0.28 5.94 4.32 0.29
10.0 4.12 3.38 0.27 4.59 3.40 0.27 4.75 3.69 0.27 5.22 4.00 0.28 5.53 3.98 0.28 5.85 4.24 0.28
15.0 4.06 3.32 0.28 4.52 3.33 0.28 4.67 3.63 0.28 5.13 3.93 0.29 5.44 3.91 0.29 5.75 4.17 0.29
19.4 4.66 3.82 0.45 5.19 3.84 0.46 5.37 4.18 0.46 5.90 4.52 0.47 6.25 4.51 0.47 6.61 4.80 0.48
25.0 4.44 3.63 0.51 4.95 3.65 0.52 5.12 3.97 0.52 5.63 4.30 0.53 5.96 4.29 0.53 6.30 4.57 0.54
30.6 4.21 3.45 0.58 4.69 3.47 0.59 4.85 3.77 0.60 5.33 4.09 0.61 5.65 4.07 0.61 5.97 4.34 0.62
35.0 3.96 3.25 0.64 4.41 3.26 0.65 4.56 3.55 0.65 5.01 3.85 0.66 5.31 3.83 0.67 5.61 4.08 0.67
40.0 3.48 2.84 0.60 3.87 2.86 0.61 4.01 3.11 0.62 4.40 3.37 0.63 4.67 3.36 0.63 4.93 3.58 0.64
46.0 2.92 2.59 0.47 3.25 2.60 0.48 3.36 2.83 0.48 3.69 3.07 0.49 3.92 3.06 0.49 4.14 3.25 0.50
- 10 -
4-1. Cooling capacity 4. Capacity table
DUCT TYPE ADUH09-18LUAS1 DUCT TYPE ADUH09-18LUAS1
