PARTS LIST
152004.04.21
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
INDOOR UNIT
26 BR Sheet 25 x 80 x 75 9305039203 9305039203
63 Front Panel Assy w/o Filter 9306817176 9306817176
65 Flow Control Panel-Z 9306571016 9306571016
69-1 Louver-A 9306583019 9306583019
69-2 Louver-C 9309884014 9309884014
74 Filter 9306601010 9306601010
89 Casing Fixture Metal 9307018008 9307018008
92 Link Plate 9306577018 9306577018
93 Link-A 9306573010 9306573010
94 Link-B 9306574017 9306574017
95 Link-C 9306575014 9306575014
96 Link-D 9606576011 9606576011
102 Link Spring 9606610012 9606610012
108 Base 9606566012 9606566012
109 Casing 9306569013 9306569013
127 Drain Hose Assy 9305550029 9305550029
146 Evaporator Assy 9308200037 9308200037
158 Connecting Pipe Assy 9309433014 9309433014
164 Fan Motor Assy-In 9306829025 9306829025
169 Cross-flow Fan Assy 9307836015 9307836015
178-1 Motor Cushion-A (Fan Motor) 9306751012 9306751012
178-2 Motor Cushion-A (Fan Motor) 9306580018 9306580018
184-1 Thermistor Spring-A 313728262708 313728262708
189 Shaft Holder-C 9306628017 9306628017
236 Controller PCB Assy 9703917028 9703917035
(EZ-00001WSE-F) (EZ-0000SHSE-F)
240 Remote Control Unit 9307979040 9307979033
268 Motor Cover-B 9306582012 9306582012
281 Clamp Metal (Pipe) 9306607012 9306607012
385 Indicator PCB Assy 9703922015 9703922015
401 Wall Hook Bracket 9306588014 9306588014
440 Flow Control Panel-U 9306570019 9306570019
557 Diffuser Spring 9306611019 9306611019
652-1 Therm. Holder Pipe 313714262805 313714262805
759 Intake Grille 9306598037 9306598037
764 Drain Cap Assy 9304150008 9304150008
767-1 Bottom Cover-A 9306567019 9306567019
777 Intake Grille Clamp 9306755010 9306755010
796 Control Box-D 9309049017 9309049017
815 Terminal 9701955022 9701955039
873 Lamp Cover 9306593025 9306593025
876-1 Step Motor 9305780006 9305780006
876-2 Step Motor 9305892006 9305892006
960 Diffuser 9306572013 9306572013
962-1 Guard Holder-L 9307229015 9307229015
962-2 Guard Holder-R 9307228018 9307228018
963 Fan Guard Metal Rod 9305751020 9305751020
B Screw (w/Spring Washer) 0700179013 0700179013
Ref.
No.
Description
Ord.
Q'ty
Part No.
Ref.
No.
Description
Ord.
Q'ty
Part No.
ASY14USACWASY14FSACW ASY14USACWASY14FSACW
OUTDOOR UNIT
4 Emblem-Rear 9308468017 9308468017
5 Cabinet Front Panel, Plastic 9305525010 9305525010
7 Connector Cover (Cabinet) 9306119010 9306119010
9 Cabinet Rear Panel, Plastic 9305526017 9305526017
12 Base Assy, Painted 9306118068 9306118068
13 3-Way Valve 9310100011 9310100011
14 2-Way Valve 9310084014 9310084014
16 Condenser Assy 9300000004 9309904002
18 Suction Pipe 9308679000 9308453013
19 Capillary Tube 9308668004
20 Discharge Pipe Assy 9308681003 9307035012
26-6 BR Sheet 100x120x T5 9305039029
26-7 BR Sheet 30x120x T7 9305039036 9305039036
26-9 BR Sheet 180x180x T2 9305039067 9305039067
26-10 BR Sheet 100x160x T5 9305039074 9305039074
32 Control Box Metal 9308561015 9308561015
34 Capacitor (Fan Motor) 9700468097 9700468097
37 Capacitor (Running) 9306512019 9306512019
38 Clamp Metal (Capacitor) 313468061808 313468061808
39 Propeller Fan 9305538003 9305538003
41 Fan Motor Assy-Out 9307715020 9307715020
42 Bracket (Motor) 9305536030 9305536030
46 Compressor Assy 9310110010 9310110010
47-2 Discharge Pipe Rubber 313185159802
(Pipe Absorber)
51 Special Nut M5 313199233602 313199233602
55 Special Nut M6 313252257701 313252257701
62 Wire Assy (Shield)-A 9395695027 9305971026
98 Fan Ring 9305581023 9305581023
107 Rubber Seat-A 9351813017 9351813017
109 Terminal Cover (Comp.) 9351120009 9351120009
138 Separate Wall 9305971008 9305971008
187 Clamp No.1219 313361271706 313361271706
195 Clamp SKB-100 313361275805 313361275805
196 Clamp SKB-150 313035356905
196-2 Clamp SKB-3MC 9305335008 9305335008
230 Overload Relay 9308443001 9308443001
343 Solenoid Coil 9307252013
344 4-Way Valve 9307609015
365 Bracket (Valve) 9306748036 9306748036
412 Terminal Gasket (Comp.) 9351121006 9351121006
420 Capillary Assy (with Check Valve) 9310134009
423 Noise Insulation-F 9310143001 9310143001
582 Discharge Pipe 9308666000 ÐÐÐÐ
620 Inlet Pipe Assy 9308455017
674 Tapping Screw (Special) 9305848010 9305848010
688 Screw (with Square Washer) 313681304205 313681304205
765 Drain Pipe 9301102000
766 Drain Pipe Packing 9301143003
815 Terminal-3P 9306489014 ÐÐÐÐ
815 Terminal-5P 9310144008 9310144008
916 Noise Insulation-G 9306362003 9306362003
935-1 Reinforcement (Cabinet Top) 9305973002 9305973002
935-2 Reinforcement-F (Cabinet Top) 9306123000 9306123000
942-1 Control Box Cover-A Metal 9308562012 9308562012
942-2 Control Box Cover-B Metal 9305975006 9305975006
981 Cord Clamp (Plastic, Black) 9302271002 9302271002
A Screw (with Inner Washer) 9357297002 9357297002
B Screw (with Spring Washer) 0700179013 0700179013
984 U Pipe (Y) D7 9308442000
X-1 Connection Pipe (Capillary) 9308667007 -------
-------
-------
-------
-------
-------
-------
-------
-------
-------
-------
-------
X-2 Dryer 9310195017 9310183014
Ref.
No.
Description
Ord.
Q'ty
Part No.
Ref.
No.
Description
Ord.
Q'ty
Part No.
AOY14USACAOY14FSAC AOY14USACAOY14FSAC
Note : Always use specified screws, since Ref. No.668, A, B and C are screws for the earth.
Ref. No.688 : Machine screw (with spring washer) M4 x P0.7 x L10, plating thickness 5µ or more
A : Tapping screw (with inner clip washer) M4 x L10, plating thickness 5µ or more
B : Machine screw (with spring washer) M4 x P0.7 x L10, plating thickness 5µ or more
C : Machine screw (with spring washer) M4 x P0.7 x L8, plating thickness 5 µ or more
To Next Page
