REFRIGERANT SYSTEM DIAGRAM
2-Way
valve
Strainer
Strainer
Sub-heat
exchanger
( INDOOR )
3-Way
valve
Muffler
4-Way valve
Expansion valve
Heat exchanger
( INDOOR )
Heat exchanger
( OUTDOOR )
Sub-accumulator
Compressor
Cooling
Heating
ASY18LSBCW / AOY18LFBC
Models : ASY14LSBCW / AOY14LFBC
Refrigerant pipe diameter
Liquid : 1/4" (6.35 mm)
Gas : 1/2" (12.7 mm)
2005.03.16
3
3
5
Table of Contents
Table of Contents
1
Specifications
2
Dimensions
2
Refrigerant System Diagram
4
Circuit Diagram
5
Error Contents
6
Indoor Pcb Circuit Diagram
8
Disassembly Illustration
12
Parts List
15
Standard Accessories
17
