When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
INDOOR UNIT
AUY25FUAR
34 Capacitor (Fan Motor) 9900270216
61 Decoration Plate 9362787000
71 Grille Hook Holder 9362782005
93 Filter 9362766005
117-3 Hex. Nut w/Spring Washer 9375072018
122 Louver Support Holder 9362799003
127 Drain Hose 9365074008
138 Separate Wall 9362793001
143-1 Clamp NK-3N 313361274700
143-3 Clamp NK-9N 313209399700
146-1 Evaporator-A Assy 9373799030
146-2 Evaporator-B Assy 9373800033
155 Special Nut M6 9307615016
160 Drain Pan Assy 9362804004
164 Fan Motor Assy-In 9601558019
168 Cabinet-E 9362735001
184-1 Thermostat Spring-A 313728262708
187 Clamp No.1219 313361271706
195 Clamp SKB-100 313361275805
197 Wind Guide Board 9373444015
223 Control Box 9362762007
226 Motor Gear 9362764001
234
Thermistor Assy-Room
9703299025
235
Thermistor Assy-Pipe
9703297014
236 Controller PCB Assy
K01AL-0401WSE-C1
9704557704
240 Remote Control Unit 9372266069
244 Pipe Cover 9362748001
253-A Wire Assy (Remote) 9372714010
337-1 Reinforcement (Eva.)-A 9362749008
337-2 Reinforcement (Eva.)-B 9362750004
338 Motor Holder 9362765008
381 Locking Spacer 313209391506
457 Reinforcement (Drain Pan) 9362757003
460-1 Pump Cover-A 9362775007
460-2 Pump Cover-B 9362776004
462 Top Cover Plate Assy 9362806022
464 Cabinet-A Assy 9362807012
465 Cabinet-B Assy 9362808019
467 Drain Port 9362786003
468 Special Nut-A (Large) 313005446653
469 Special Nut-B (Small)
313005446759
472-1 Grille Reinforcement-A
9362738002
472-2 Grille Reinforcement-B
9362739009
472-3 Grille Reinforcement-C
9362740005
472-4 Grille Reinforcement-D
9362741002
472-5 Grille Reinforcement-E
9362742009
479 Float Switch 9703285004
482 Pump Unit 9703125010
484 Hook 9362736008
487 Grille Hinge Wire 9362754002
488 Drain Pan Plug 313005174654
514 Control Box Cover 9362763004
522 Joint Gear 9362772006
541 Terminal Plate 9363642001
Ref.
No.
Description
Ord.
Q'ty
Part No.
AUY25FUAR
Ref.
No.
Description
Ord.
Q'ty
Part No.
PARTS LIST
542 Panel Base 9362759014
543 Panel Frame Holder 9362761017
544 Panel Base Holder 9362760010
545 Panel Frame 9362758017
563 Insulation (Inner Box) 9362797009
565 Evaporator Holder Assy 9362802024
628 Locking Spacer-B 313005446558
690 Joint-A 9362773003
692 Joint Shaft 9362771009
705 Louver 9362769013
710 Intake Grille 9362767019
735 Distributor Assy 9371325040
777-1 Grille Hook-A 9362779012
777-2 Grille Hook-B 9362778015
798 Pump Hook Bracket 9362753005
803 Cabinet-D 9362792004
814 Cabinet-C 9362791007
815-1 Terminal-3P 9306489069
815-2 Terminal-3P 9703345012
824-3 Fuse 0600222512
834-1 Wire Cover-A 9362789004
834-2 Wire Cover-B 9362788007
835 Cushion Rubber (Pump) 9362777001
847 Louver Supporter 9362770019
858 Grille Spring 9362755009
875 Filter PCB Assy 9704561107
876-2 Step Motor 9900362027
903 Rubber (Vibration-proof) A 9364891002
904 Rubber (Vibration-proof) B 9364892009
982-1 Cord Clamp 9356857009
477 Bellmouth (B) 9362774000
2006.03.31 15
474 Turbo Fan Assy
9362810012
476-2 Special Washer 9362756006
