REFRIGERANT SYSTEM DIAGRAM
Cooling
: Flare coupling
Models : AUY25FUAR / AOY25FNAKT
Strainer
Refrigerant pipe
15.88 mm (5/8")
Refrigerant pipe
9.52 mm (3/8")
Capillary tube
Charging valve
Compressor
OUTDOOR UNITINDOOR UNIT
Evaporator
Condenser
2006.03.30 4
