When you order parts, please make a photocopy of this page and
fill the number of the parts in the "Order" column.
2005.08.01 23
OUTDOOR UNIT
1 Top Panel Sub Assy 9374417018 9374417018
2
Front Panel-L, Painted
9374094042 9374094042
3 Fan Guard 9374330010 9374330010
4 Side Grip 9374173013 9374173013
5 Service Panel Assy 9374093045 9374093045
6 Right Panel Assy 9374095049 9374095049
8 Propeller Fan Assy 9366378013 9366378013
9 Motor, Induction 9601671060 9601671060
10 Condenser-A Assy 9374433049 9374433032
11
Condenser-B Assy
9374434046 9374434039
12 Strainer Assy 9372524015 9372524015
13 Separate Wall Sub Assy 9374413058 9374413058
14 Cap Foot 9374345014 9374345014
15 Base Assy 9374166046 9374166046
17 3-Way Valve Assy (3/8) 9372205044 9372205044
18 3-Way Valve Assy (5/8) 9372205075 9372205075
19 Check Joint Assy 9372802038 9372802038
20
Compressor Assy
9372558096 9372558096
21 Rubber Seat (For Comp. )-A 9351049010 9351049010
---- Belt Heater 9361140257 9361140257
22 4-Way Valve --------- 9900164010
23
Solenoid
--------- 9900165055
24 Pressure Switch 9900276010 9900186012
----
Accumulator Support-B Assy 9355350006 ---------
---- Accumulator Holder Rubber 9354022010 ---------
41 Thermostat Overheat 9354061002 ---------
42 Controller PCB Assy --------- 9705677036
43
44
Thermistor Spring --------- 9372140017
---- Shield Tube-S 9352307041 ---------
---- Thermistor Assy --------- 9900274016
---- Varistor --------- 0000515610
---- Fuse 6.3A-250V --------- 0600222574
---- Fuse Holder --------- 0500158072
---- Protective Net-L 9374255023 9374255023
---- Drain Pipe (I-Yipe) --------- 9301102000
---- Drain Packing --------- 9301143003
---- Drain Cap --------- 313166024302
---- Emblem Rear 9351355005 9351355005
Ref.
No.
Description
Ord.
Q'ty
Part No.
AOY36UNAXTAOY36FNAXT
26 Capillary Assy 9372197318 ---------
27 Capillary Holder Rubber 313394274808 313394274808
28
30
Expansion Valve Assy --------- 9370947090
33 Terminal HP-T3041-B7-L0 9363276039 9363276039
34
35
36
Terminal HP-T4005-21 9701971015 ---------
37 Capacitor, Plastic 9900270049 9900270049
(For Fan Motor)
38 Magnetic Relay 9900227012 9900227012
39 Relay 9900287016 ---------
40 Outdoor Thermostat 9900275013 ---------
Outlet Pipe 9374266036 9974266029
Control Box 9374164011 9374164011
Fuse 0600376086 0600376086
Fuse Holder 0501456016 0501456016
