REFRIGERANT SYSTEM DIAGRAM
OUTDOOR UNIT
Pressure
Check Valve
High
Pressure
Switch
Condenser
Accumulator
Compressor
Strainer
Capillary
Tube
Charging
Valve
15.88mm (5/8")
INDOOR UNIT
Evaporator
Refrigerant Pipe
9.52mm (3/8")
Charging Valve
OUTDOOR UNIT
Pressure
Check Valve
Condenser
4-way
Valve
Muffler
High
Pressure
Switch
Accumulator
Compressor
Muffler
Expansion
Valve
Refrigerant Pipe
9.52mm (3/8")
Charging Valve
Evaporator
Charging
Valve
Refrigerant Pipe
15.88mm (5/8")
INDOOR UNIT
Strainer
Strainer
: COOL
: HEAT
Models : AUY36FUAS / AOY36FNAXT
Models : AUY36UUAS / AOY36UNAXT
Refrigerant Pipe
2005.08.01 5
