PARTS LIST
When you order parts, please make a photocopy of this page and
fill the number of the parts in the "Order" column.
INDOOR UNIT
34 Capacitor, Plastic (For Fan Motor) 9900270162 9900270162
47-1 Rubber (Discharge Pipe) 313194159807 313194159807
61 Decoration Plate 9362787000 9362787000
67 Rubber (Vibration-proof) 9362783002 9362783002
71 Holder (Hook) 9362782005 9362782005
93 Filter 9362766005 9362766005
117-3 Hexagon Nut (Spring Lock Washer)301721180114 301721180114
122 Holder (Louver Supporter) 9362799003 9362799003
127 Drain Hose 9362784009 9362784009
---- Insulation (Drain Hose) 9363266009 9363266009
138 Separate wall Sub Assy 9362824018 9362824018
---- Seal (Separate Wall) 9363147001 9363147001
143-1 Clamp NK-3 313361274700 313361274700
---- Evaporator Sub Assy 9362817288 9362817288
146-1 Evaporator-A Assy 9373799054 9373799054
146-2 Evaporator-B Assy 9373800057 9373800057
155 Special Nut M6 9307615016 9307615016
160 Kit (Drain Pan Sub Assy) 9370934014 9370934014
164 Motor, Induction 9601915010 9601915010
168 Cabinet-E Sub Assy 9362831017 9362831017
184-1 Thermistor Spring-A 313728262708 313728262708
187 Clamp No. 1219 313361271706 313361271706
195 Binder-C 313361275805 313361275805
197 Wind Guide Board 9373444015 9373444015
223 Control Box 9362762007 9362762007
226 Motor Gear 9362764001 9362764001
234 Room Temperature Thermistor 9703299025 9703299025
235 Pipe Temperature Thermistor 9703297014 9703297014
236 Controller PCB Assy 9704557902 9704557896
240 Remote Control Unit 9372266069 9372266052
244 Pipe Cover Sub Assy 9362819015 9362819015
253-A Wire Assy 9372714010 9372714010
337-1 RFM (Eva. )-A 9362749008 9362749008
337-2 RFM (Eva. )-B 9362750004 9362750004
338 Motor Holder 9362765008 9362765008
381 Locking Spacer 313209391506 313209391506
457 RFM (Drain Pan) 9362757003 9362757003
460-1 Pump Cover-A 9362775007 9362775007
460-2 Pump Cover-B 9362776004 9362776004
462 Panel (Top) Sub Assy 9362815017 9362815017
464 Cabinet-A Assy 9362800013 9362800013
465 Cabinet-B Assy 9362801010 9362801010
467 Drain Port 9362786003 9362786003
468 M10 Nut-A (Large) 313005446653 313005446653
469 M10 Nut-B (Small) 313005446759 313005446759
472-1 RFM (Grille)-A 9362738002 9362738002
472-2 RFM (Grille)-B 9362739009 9362739009
479 Float Switch 9703285004 9703285004
481 Insulation (Grille)-A 9362780001 9362780001
481-1 Insulation (Grille)-B 9362781008 9362781008
482 Pump Assy 9703125010 9703125010
484 Hook 9362736008 9362736008
487
488
Hinge Wire (Grille) 9362754002 9362754002
514 Control Box Cover 9362763004 9362763004
522 Joint Gear 9362772006 9362772006
541 Terminal Plate 9363642001 9363642001
542 Panel Base 9362759014 9362759014
543 Holder (Panel Frame) 9362761017 9362761017
544 Holder (Panel Base) 9362760010 9362760010
545 Panel Frame 9362758017 9362758017
563 Inner Box Sub Assy 9362814010 9362814010
564 Bypass Pipe-A Assy 9371323053 9371323053
565 Evaporator Holder Assy 9362802017 9362802017
568 Acoustic Seat 9363143003 9363143003
628 Locking Spacer-B 313005446558 313005446558
690 Joint-A 9362773003 9362773003
692 Joint Shaft 9362771009 9362771009
705 Louver Sub Assy 9362836012 9362836012
710 Intake Grille Sub Assy 9362818117 9362818117
735 Distributoe Assy 9371325132 9371325132
777-1 Hook (Grille)-A 9362779012 9362779012
777-2 Hook (Grille)-B 9362778015 9362778015
798 Drain Pump Holder 9362753005 9362753005
---- Insulation (Pump Holder)-A 9363704006 9363704006
803 Cabinet-D 9362734004 9362734004
814 Cabinet-C 9362733007 9362733007
815-1 Terminal-3P 9306489069 9306489069
815-2 Terminal-3P 9703345012 9703345012
834-1 Cover (Wire)-A 9362789004 9362789004
834-2 Cover (Wire)-B 9362788007 9362788007
835 Cushion (Pump) 9362777001 9362777001
847 Louver Supporter 9362770019 9362770019
858 Spring (Grille) 9362755009 9362755009
875 Power Supply PCB Assy 9704561237 9704561220
876-2 Motor, Step 9360307019 9360307019
896 Coupling Pipe Assy 9373038221 9373038221
982-1 Clamp (Cord) 9356857009 9356857009
Ref.
No.
Description
Ord.
Q'ty
Part No.
Ref.
No.
Description
Ord.
Q'ty
Part No.
AUY36UUASAUY36FUAS AUY36UUASAUY36FUAS
2007.04.25 22
472-3 RFM (Grille)-C 9362740005 9362740005
472-4 RFM (Grille)-D 9362741002 9362741002
472-5 RFM (Grille)-E 9362742009 9362742009
474 Turbo Fan Assy 9362803014 9362803014
476-2 Washer (Turbo Fan) 9362756006 9362756006
477 Bellmouth-B 9362774000 9362774000
Prain Pan Plug 313005174654 313005174654
652-1
143-3 Clamp NK-9N 313209399700 313209399700
Thermistor Holder Pipe 313806262805 313806262805
