OUTLINE AND DIMENSIONS
296
750
940
30
60
285
120
150
120
150
(Small pipe)
(Drain pipe)
60
(Drain pipe)
(Large pipe)
(Small pipe) (Large pipe)
250
750
940
305.5
298.5
248.5
305.5
Drain Inside Dia. 32
Dia. 37Outside
298.5
248.5
(Unit : mm)
INDOOR UNIT
Models : AUY54FUAS
AUY54UUAS
