42003.11.20
BLACK
BLACK
WHITE BLUE
WHITE
RED
ORANGE
WHITE RED
INDOOR UNIT
OUTDOOR UNIT
CM
FM
TERMINAL
COMPRESSOR
FAN MOTOR
FAN MOTOR
CAPACITOR
OVERLOAD
RELAY
COMPRESSOR
CAPACITOR
N L
R C
S
CIRCUIT DIAGRAM
Models : ASY7FSBCW / AOY7FSBC
