Fujitsu AOY90EPD3L User Manual

232003.10.17
Ref.
No.
Description
AOG90EPD3L AOG90TPC3L
AOY90EPD3L AOY90TPC3L
Ord.
Q'ty
Part No.
Ref.
No.
Description
AOG90EPD3L AOG90TPC3L
AOY90EPD3L AOY90TPC3L
Ord.
Q'ty
Part No.
OU T DOOR UN IT
2 Fan Cover 9366142010 9366142010
4 Emblem-Rear "FUJITSU" 9371388014 9371388014
4 Emblem-Rear "GENERAL" 313791088308 313791088308
9 Rear Panel, Painted 9361712027 9361712027
12 Base Assy 9372336014 9372336014
15 Dryer 9369978012 9369978012
16-1 Condenser-A Assy 9370620016 9370620016
16-2 Condenser-B Assy 9370621013 9370621013
20 Discharge Pipe Assy 9365569009 -----
21 Discharge Pipe - B Assy ----- 93 65567005
26 Compressor Cover-A 9361935006 9361935006
32 Control Box 9361713000 9361713000
34 Capacitor (Fan Motor) 9703306037 9703306037
39 Propeller Fan 9361726000 9361726000
41 Fan Motor Assy-Outer 9601698012 9601698012
42 Bracket Panel (Motor) 9361703001 9361703001
45 Bracket (Motor) 9361701007 9361701007
46 Compressor Assy 9367378005 9367378005
55 Special Nut M8 313252257701 313252257701
69-3 Bolt , Hex.Socket 301210060360 301210060360
82 Check Joint Assy 9363886009 9363886009
85 Valve Plate 9363063004 9363063004
86 Gasket 9363272000 9363272000
87 Bracket (Compressor) 9361694002 9361694002
100 Base Foot , Painted 9361688025 9361688025
117-3 Special Washer M6 313306391007 313306391007
132 Front Protection Net 9366144014 9366144014
133 Front Panel - L 9361709027 9361709027
134 Front Panel - R 9361710047 9361710047
160 Drain Pan 9361700000 9361700000
164 Separate Wall - Upper 9361693005 9361693005
166 Separate Wall - L 9361695009 9361695009
167 Separate Wall - R 9361696006 9361696006
172 Pipe Cover 9363470000 9363470000
176 Bracket (Valve) - A 9368955007 9368955007
184-1 Thermostat Spring-A 313728262708 313728262708
185 Rubber Bushing 313005066051 313005066051
187 Clamp No.1219 313361271706 313361271706
195 Clamp SKB - 100 313361275805 313361275805
196-1 Clamp SKB - 3M 312300787605 312300787605
196-2 Clamp SKB - 150 313035356905 313035356905
226 Reinforcement (Separate Wall) 9361697003 9361697003
236 Controller PCB Assy 9704764102
245 Condensing Pipe - M 9367200009
9704764164
9367200009
272 Strainer 9361931008 9361931008
289 Reinforcement (Side Panel) 9361704008 9361704008
320-1 Wire Clamp Metal 313483219905 313483219905
327 Suction Pipe - A 9365599006 9365599006
333 Accumulator 9371828015 9371828015
334 Suction Pipe - B ---------- 9361894006
343 Solenoid Coil ---------- 9703342011
344 4-Way Valve ---------- 9703270000
347 Noise Insulation - D 313712304109 313712304109
354 Pressure Switch 9703667008 9703667008
355 Bracket (Condenser) - L 9361698000 9361698000
356 Bracket (Condenser) - R 9361699007 9361699007
361 Bushing 9361725003 9361725003
363 Bracket Panel (Comp.) 9361691018 9361691018
376 Bracket (Control Box) 9361727007 9361727007
381-2 Locking Spacer KGLS-8S 0600035020 0600035020
381-3 Locking Spacer KGPS-8S 0600118051 0600118051
405 Clamp No.1763 313816345304 313816345304
407 Clamp(Cable) No.1259 313739340109 313739340109
450 Discharge Pipe - A ----- 9367217007
477 Bellmouth 9361721005 9361721005
527 Condenser Guard 9366143017 9366143017
646 Compressor Cover - B 9361936003 9361936003
652-1 Thermistor Holder Pipe 313714262805 313714262805
653 Bolt, For Fan Motor 0700145087 0700145087
678 Bracket (Thermistor) 313557406106 313557406106
761 Side Panel - R, Painted 9361706026 9361706026
762 Side Panel - L, Painted 9361705029 9361705029
790-1 Belt Heater - A 9361140042 9361140042
790-2 Belt Heater - B 9361140059 9361140059
791 Magnetic Relay 9900078010 9900078010
809 Ball Valve - A 9371799025 9371799025
810 Ball Valve - B 9361938007 9361938007
815-1 Terminal 5P 9363275018 9363275018
815-2 Terminal 4P 9363276015 9363276015
816 Wire Clamp Metal 313584219902 313584219902
825 Expansion Valve Assy 9366558002 9365566008
829 Joint Pipe Assy 9362922005 9361886001
880-1 Network (C - R) 9700987017 9700987017
918 Thermistor Assy 9900125011 9900125011
919-2 Expansion Valve Coil 9361930001 9361930001
942 Control Box Cover 9361716001 9361716001
949-1 Screw, Painted 9305648009 9305648009
949-2 Screw, Painted 9302348001 9302348001
964 Flare Nut 9371800028 9371800028
966 Bonnet 9371801025 9371801025
982-1 Cord Clamp 9356857009 9356857009
982-2 Cord Clamp - B 9356858006 9356858006
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
AOG90EPD3L
AOG90TPC3L
AOY90EPD3L
AOY90TPC3L
