Fujitsu AOY90EPD3L User Manual

222003.10.17
Ref.
No.
Description
ARG90ELC3 ARG90TLC3
ARY90ELC3 ARY90TLC3
Ord.
Q'ty
Part No.
ARG90ELC3
ARG90TLC3
ARY90ELC3
ARY90TLC3
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
10 Front Panel Assy 9364635002 9364635002
45-1 Bracket (Motor) Assy 9364630007 9364630007
51
Nut
0700005091 0700005091
56-1 Sirocco Fan-R 9364665016 9364665016
56-2 Sirocco Fan-L 9364665023 9364665023
64 Left Panel 9364650005 9364650005
69 Right Panel 9364649009 9364649009
75 Fan Panel 9364629001 9364629001
86 Gasket 9363272000 9363272000
109 Casing Assy 9364660004 9364660004
126 Motor Plate Assy 9364632001 9364632001
146 Evaporator Assy 9370825015 9370825015
160 Drain Pan Assy 9364652023 9364652023
164 Fan Motor Assy-In 9601004004 9601004004
184-1 Thermo. Spring-A 313728262708 313728262708
187 Clamp No.1219 313361271706 313361271706
195 Clamp SKB-100 313361275805 313361275805
223 Control Box Metal 9365185001 9365185001
233-1 Plate (Box) 9365146002 9365146002
234 Thermistor Assy-Room 9703299056 9703299056
235 Thermistor Assy-Pipe 9703297021
9704557520
9703297021
236 Controller PCB Assy 9704557377
240 Remote Control Unit 9703173066 9371438030
273 Rear Panel Assy 9364642000 9364642000
287 Cap (Power) 9352173011 9352173011
320-1 Wire Clamp Metal 313483219905 313483219905
324 Top Plate 9364634005 9364634005
INDOOR U N IT
Ref.
No.
Description
ARG90ELC3 ARG90TLC3
ARY90ELC3 ARY90TLC3
Ord.
Q'ty
Part No.
329 Coupling Pipe Assy 9365347003 9365347003
380 Locking Spacer KGLS-6S 313209391403 313209391403
381-4 Locking Spacer KGPS-6S 0600118075 0600118075
405 Panel Side 9364648002 9364648002
466 Clamp NK-4N 313714328805 313714328805
468 Nut-A M8 9356998009 9356998009
477 Bellmouth 9364664002 9364664002
495 Clamp No.2U46 9352715006 9352715006
514 Control Box Cover Metal 9365186008 9365186008
625 Cord Bushing 9359240006 9359240006
652-1 Therm. Holder Pipe 313806262805 313806262805
653-2 Bolt HLSJ8025ZV 0700190018 0700190018
674 Bolt LSM10045 0700145117 0700145117
735 Distributor Assy 9365343005 9365343005
761 Side Panel-R Assy 9365147009 9365147009
791 Magnetic Relay 9900002015 9900002015
815-1 Terminal 3P 9356488005 9356488005
815-2 Terminal 3P 9363276046 9363276046
815-3 Terminal 3P 9703345012 9703345012
824-3 Fuse 0600222512 0600222512
875 Filter PCB Assy 9704561145 9704561145
943 Wire Clamp 0600231019 0600231019
967 Bonnet-B 313045417959 313045417959
982-1 Cord Clamp 9356857009 9356857009
982-2 Cord Clamp-B 9356858006 9356858006
995 Beam 9364647005 9364647005
996 Drain Pan (S) Assy 9364893013 9364893013
PARTS LIS T
