INDOOR UNIT
43 Top Cover
R and L Louver U46
Parts numberDescriptionRef
9316207011
9316208018
Casing
49
9316204010
Fan Guard 9316211018
192008.01.21
58
43
49
55
56
57
54
53
52
51
50
46
Bushing B
50
9312156016
Bushing A
51
9303529010
Motor Step (up / down)
54
9900384043
Gear A
53
9309994003
Gear Case
52
9316213012
REF (Casing)
57
58 9316378018
Louver Z
56
9316206014
Louver U
55
9316205017
