Fujitsu AOYA18LAT3 User Manual

OUTDOOR UNIT
Inverter assy
23
Connector : BLACK
Connector : RED
GREEN
BLUE
RED
YELLOW
WHITE
47
60
61
62
45
46
48
5050
51
49
58
55
56
55
43
59
54
54
44
68
67
66
65
64
63
69
45 Inverter Box C
46 Inverter Box Duct
47 Inverter Box Cover
48 Heat Sink A
49 Inverter Box D
50 Terminal (6P)
54 Fuse Holder (Big)
55 Fuse Holder (Small)
56 Fuse (Big)
57 Fuse (Small)
58 Terminal (2P)
59 ACTPM
60 Power Supply PCB Assy
9375140014
9374609017
9375139018
9375138011
9374606023
51 Terminal (3P) 9306489045
9900016036
0501454012
0501456016
0600086039
0600376116
9701971015
9703457012
9705647091
61 Controller PCB Assy (24LAT3)
62 Holder (Thermo)
63 Heat Sink Thermistor
64 Compressor Temp Thermistor
65 Thermistor (Outdoor Temp)
66 Heat Exchanger Thermistor
67 Discharge Temp Thermistor
68 Wire (Pressure Sw) (Red)
69 Wire (Pressure Sw) (White)
9705642195
61 Controller PCB Assy (18LAT3) 9705642225
9372797013
9900311018
9900156053
9900378028
9900374020
9704219039
9377823014
9377823021
Ref. Description Part number
43 Inverter Box A
44 Inverter Box B Assy
9374603015
9374625024
2008.01.21
