INDOOR UNIT
Drain pan
Flap
2007.10.26 19
3
27
28
29
2
32
33
31
30
3
28
34
35 Kit (Separate Wall Sub Assy) 9371366029
21 Evaporator Assy 9372585078
Drain Pan Sub Assy 936042901827
24 Kit (Panel pipe-L) Sub Assy 9371362014
25 Kit (Panel pipe-R) Sub Assy 9371363011
28 Flap Assy 9359731009
29 Bushing 9359733003
-- Drain Cap 9358746004
23 Coupling Pipe Assy 9373038405
2 Panel Left Sub Assy 9360427014
3 Kit (Panel Right Assy) 9371361017
26 Reinforcement Metal 9359697008
31 Sector Gear 9359729006
30 Flap Spring 9359730002
32 Pinion 9359728009
33 Motor Base 9359727002
22 Distributor Assy 9371325378
36 Pipe Fixture Metal 9359688006
-- Thermistor Spring A
313728262708
-- Pipe Thermistor 9900022020
34 Step Motor V 9900297015
Ref.
Description Part number
