Top view
690(Bolt pitch)
530(Bolt pitch)
732(Bolt pitch)
8-12x17(Hole)
765
930
1690
1576
1339
80
Front view
A, C
B
Right view
Left view
Rear view
2010.02.17
OUTDOOR UNIT
(unit : mm)
4
