Fujitsu AOYD45LATT User Manual

5V
PHA201
P I C-37143TH5
C202
10/
25V
+
C201
0.1
<F>
SW201
EVQPAG04K
R201 220 <1/4W>
R202 390 <1/4W>
R203 560 <1/4W>
D201 SLR-325MC <GREEN>
D202 SLR-325DC <ORANGE>
D203 SLR-325VC <RED>
CN201
S07B-PASK-2 (LF) (SN)
6
7
5
4
3
2
1
2
1
4 3
VCC
OUT
GND
2
1
3
OPERATE
TIMER
FILTER CLEAN / FILTER SIGN
5V
REMOTE CONTROL SIGNAL
GRAND
MANUAL AUTO SWICTH
TO CONTROLLER PCB ASSEMBLY
2008.12.11 17
CASSETTE TYPE
INDOOR UNIT
INDICATOR PCB ASSEMBLY
K06AG-0700HSE-D0
