Page #55 background imageLoading...
Page #55 background image
28
29
24
21
27
27
26
28
25
23
24
22
DUCT TYPE
INDOOR UNIT
ARYF18LBLU
2008.04.30 54
24 Sirocco Fan Assy 9385258006
28 Rubber (Vibration-proof) 9385102002
23 Casing Assy 9363322002
25 Motor Fixing Table Assy 9358591000
22 Panel Assy (Motor) 9363401004
26 Fan Motor Assy 9602401017
29 Room Thermistor 9703299018
27 Motor Fixture 9358594001
21 Top Panel Sub Assy 9364507026
Ref. Description Part number
