2018.03.01 3
DIMENSIONS
INDOOR UNIT
ASYG07KMTA
ASYG09KMTA
ASYG12KMTA
ASYG14KMTA
15.8 to 16.7
Drain hose
Diameter
Outside
Inside : 13.8 mm
600 mm
270 mm
222 mm834 mm

Other manuals for Fujitsu AOYG12KMTA

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Fujitsu AOYG12KMTA and is the answer not in the manual?

Fujitsu AOYG12KMTA Specifications

General IconGeneral
TypeAir conditioner outdoor unit
Multi-splitNo
Product colorWhite
Gas hose diameter9.5 mm
Hose length (max)15 m
Inverter technologyYes
Liquid hose diameter6.35 mm
Refrigerating mediumR32
Air conditioner functionsCooling, Heating
Refrigerating medium weight700 g
Cooling capacity in watts (nominal)- W
Operating temperature (cooling) (T-T)-10 - 46 °C
Operating temperature (heating) (T-T)-15 - 24 °C
Seasonal efficiency rating (cooling) (SEER)-
AC input voltage230 V
Current (cooling)6.5 A
Current (heating)9 A
AC input frequency50 Hz
Design load (cooling)- kW
Hourly energy consumption (cooling)- kWh
Indoor unit noise level (high speed)- dB
Outdoor unit depth290 mm
Outdoor unit width663 mm
Outdoor unit height541 mm
Outdoor unit weight25000 g
Outdoor units quantity1
Outdoor unit noise level58 dB
Cooling airflow (outdoor unit)770 m³/h
Outdoor unit sound power level50 dB
