2013.02.28 17
21 Reactor Assy 9900787028
22 PCB Holder 9332506006
23
Main PCB with Terminal (09)
9709435038
23
Main PCB with Terminal (07)
9709435052
23
Main PCB with Terminal (12)
9709435045
-- Thermistor Assy 9900719029
-- Thermistor 9900717025
24 Heat Sink B 9332522006
Ref. Description Part number
OUTDOOR UNIT
23
22
23
24
21
