INDOOR UNIT DECORATION PANEL
D I MEN S I O N S
2011.12.12 2
Unit : mm
530 : Hanging bolt position
102
135 250
700
700
75
30
30
262
540 : Hanging bolt position
Ceiling openings
Decoration panel mounting state
150 to 200Min. 450
Min. 450
Maintenance space
215
123
58
114
146
108
102
245
30
40 99
Drain port
Ceiling
Drain port
Be sure to leave
maintenance space
for future service
at the designated
position.
30
49
