Fujitsu AOYG14LMCA User Manual

PARTS
9
5
4
11
6
12
8
3
10
1
2
INDOOR UNIT
2013.04.10 13
6
9
11
8
10
Intake Grille (FUJITSU) 9333052007
7 Front Panel Sub Assy (FUJITSU) 9332994001
3 Bracket Panel 9332882018
4
Wire Cover 9332894004
Wire Shield 9332906004
Electric Filter Holder 9332911008
5 Air Clean Filter Assy 9317250009
1 Remote Control 9319208008
2 Remote Control Holder 9318912005
Ref. Description Part number
Air Filter 9332875003
Louver 9332900002
12 Diffuser Assy 9332998009
7

Fujitsu AOYG14LMCA Specifications

General

Brand	Fujitsu
Model	AOYG14LMCA
Category	Air Conditioner
Language	English
