En-10
CAUTION
After turning off the power, wait 10 seconds or more before turning on it again.
The Function Setting does not become active unless the power is turned off then on
again.
Filter sign
Select appropriate intervals for displaying the fi lter sign on the indoor unit according to the
estimated amount of dust in the air of the room.
If the indication is not required, select “No indication” (03).
(♦... Factory setting)
Setting Description
Function
Number
Setting Value
Standard (400 hours)
11
00
Long interval (1,000 hours) 01
Short interval (200 hours) 02
♦ No indication 03
Room temperature control for cooling
Depending on the installed environment, correction of the room temperature sensor may
be required. Select the appropriate control setting according to the installed environment.
(♦... Factory setting)
Setting Description
Function
Number
Setting Value
♦ Standard
30
00
Slightly lower control 01
Lower control 02
Higher control 03
Room temperature control for heating [Reverse cycle model only]
Depending on the installed environment, correction of the room temperature sensor may
be required. Select the appropriate control setting according to the installed environment.
(♦... Factory setting)
Setting Description
Function
Number
Setting Value
♦ Standard
31
00
Lower control 01
Slightly higher control 02
Higher control 03
Auto restart
Enable or disable automatic restart after a power interruption.
(♦... Factory setting)
Setting Description
Function
Number
Setting Value
♦ Enable
40
00
Disable 01
* Auto restart is an emergency function such as for power outage etc. Do not attempt to
use this function in normal operation. Be sure to operate the unit by remote controller or
other external input device.
Room temperature sensor switching
(Only for wireless remote controller)
When using the Wired remote controller temperature sensor, change the setting to “Both”
(01).
(♦... Factory setting)
Setting Description
Function
Number
Setting Value
♦ Indoor unit
42
00
Both 01
00: Sensor on the indoor unit is active.
01: Sensors on both indoor unit and wired remote controller is active.
Remote controller custom code
(Only for wireless remote controller)
The indoor unit custom code can be changed. Select the appropriate custom code.
(♦... Factory setting)
Setting Description
Function
Number
Setting Value
♦ A
44
00
B01
C02
D03
External input control
“Operation/Stop” mode or “Forced stop” mode can be selected.
(♦... Factory setting)
Setting Description
Function
Number
Setting Value
♦ Operation/Stop mode
46
00
(Setting prohibited) 01
Forced stop mode 02
Indoor unit fan control for energy saving for cooling
Enables or disables the power-saving function by controlling the indoor unit fan rotation when
the outdoor unit is stopped during cooling operation.
(♦... Factory setting)
Setting Description
Function
Number
Setting Value
Disable
49
00
♦ Enable 01
00: When the outdoor unit is stopped, the indoor unit fan operates continuously following
the setting on the remote controller.
01: When the outdoor unit is stopped, the indoor unit fan operates intermittently at a very
low speed.
Setting record
Record any changes to the settings in the following table.
Setting Description Setting Value
Filter sign
Room temperature control for cooling
Room temperature control for heating
Auto restart
Room temperature sensor switching
Remote controller custom code
External input control
Indoor unit fan control for energy saving for
cooling
After completing the FUNCTION SETTING, be sure to turn off the power and turn it on
again.
15. CUSTOMER GUIDANCE
Explain the following to the customer in accordance with the operating manual:
(1) Starting and stopping method, operation switching, temperature adjustment, timer, air
fl ow switching, and other remote control unit operations.
(2) Air fi lter removal and cleaning, and how to use the air louvers.
(3) Give the operating manual to the customer.
9333005072_IM.indb 109333005072_IM.indb 10 2013-9-24 11:45:182013-9-24 11:45:18
