INDOOR UNIT
Control box
14
Terminal 9900720001
Main PCB 9709427200
13
Earth terminal
Control Box11
Cover shield
9332892000
Box shield assy
12
15
Room Thermistor Holder
9332868005
Ref. Description Part number
14
-- Thermistor Assy 9900714024
Display Assy 9709430019
2013.09.24
12
11
15
14
13
