Item no. Part no. Part name Service part
1 9387480023 Bracket panel ♦
2 9387471007 Louver spring ♦
3 9333608006 Bush ♦
4 9387714036 Stepping motor holder assy ♦
5 9901011047 Stepping motor ♦
6 9387590166 Drain pan total assy ♦
7
9333766072 Blow panel assy (07—14KETF) ♦
9333766089 Blow panel assy (07—14KETF-B) ♦
8
9384066008 Screw cover R (07—14KETF) ♦
9384066015 Screw cover R (07—14KETF-B) ♦
9
9384065001 Screw cover L (07—14KETF) ♦
9384065018 Screw cover L (07—14KETF-B) ♦
10
9387479003 Horizontal louver assy (07—14KETF) ♦
9387479034 Horizontal louver assy (07—14KETF-B) ♦
11
9387597066 Wire cover assy (07—14KETF) ♦
9383729034 Wire cover assy (07—14KETF-B) ♦
12
9387596304 Front panel total assy (07—14KETF) ♦
9387596311 Front panel total assy (07—14KETF-B) ♦
13
9384059000 Decoration panel R (07—14KETF) ♦
9384059017 Decoration panel R (07—14KETF-B) ♦
14
9384062000 Side panel R (07—14KETF) ♦
9384062017 Side panel R (07—14KETF-B) ♦
15 9333704005 Grille clamper R ♦
16
9384140067 Under cover assy (07—14KETF) ♦
9384140098 Under cover assy (07—14KETF-B) ♦
17
9384067005 Display plate (07—14KETF) ♦
9384067012 Display plate (07—14KETF-B) ♦
18
9387756159 Intake grille assy (07—14KETF) ♦
9387756166 Intake grille assy (07—14KETF-B) ♦
19 9333719009 Grille clamper L ♦
20
9384058003 Decoration panel L (07—14KETF) ♦
9384058010 Decoration panel L (07—14KETF-B) ♦
21
9384061003 Side panel L (07—14KETF) ♦
9384061010 Side panel L (07—14KETF-B) ♦
22 9387473018 Air filter ♦
23 9316177017 Drain cap ♦
24 9316904002 Drain hose assy ♦
25 9332453041 Remote controller holder ♦
26 9332438734 Remote controller ♦
— 9901010071
Wire with connector (CN75 on Main PCB—WLAN
adapter)
♦
a — Stepping motor holder —
b — Shaft cover —
c — Spacer H assy —
d — Wire cover B assy —
e — Front panel —
3-4. Wall mounted type - (02-81) - 3. Indoor unit parts list
