Item no. Part no. Part name Service part

9387587098 Base assy (07—14KETF) ♦

9387587104 Base assy (07—14KETF-B) ♦

51 9383765056 WLAN adapter holder assy ♦

52 9384563040 WLAN adapter ♦

9711732781 Main PCB (07 model) ♦

9711732798 Main PCB (09 model) ♦

9711732804 Main PCB (12 model) ♦

9711732811 Main PCB (14 model) ♦

54 9387488012 Cable guide ♦

55 9711382009 Display assy ♦

56 9711358004 Display PCB ♦

57 9901013010 Terminal 3P ♦

58 9384500014 Motor case sub assy ♦

9603768003 DC fan motor (07—12 models) ♦

9603631017 DC fan motor (14 model) ♦

60 9387713022 Motor cover assy ♦

61 9317250009 Air clean filter assy ♦

62 9332911008 Electric filter holder ♦

9387593143 Evaporator total assy (07—12 models) ♦

9387593150 Evaporator total assy (14 model) ♦

64 9900627041 Thermistor assy ♦

65 9387467000 Room thermistor holder ♦

66 9333628004 Bearing D assy ♦

67 9387055047 Crossflow fan assy ♦

a — Box shield —

b — Control box —

c — PCB holder A —

d — Motion sensor —

e — Front panel cover B assy —

f — Display case assy —

g — Control cover —

3-4. Wall mounted type - (02-83) - 3. Indoor unit parts list
