Item no. Part no. Part name Service part
100 9316412057 Drain pan assy ♦
101 9316217010 Limit switch cover ♦
102 9316218017 Key top ♦
103 9316177017 Drain cap ♦
104 9316214026 Drain pan U ♦
105 9711683007
Wire with connector
(Refrigerant leak detect sensor—P410 on Main PCB)
♦
106 9901089008 Refrigerant leak detect sensor ♦
107 9384838001 Sensor cover seal ♦
108 9384709004 Sensor cover ♦
109 9314147029 Drain hose assy ♦
110 9316384019 Drain hose holder ♦
111 9312156016 Bushing B ♦
112 9303529010 Bushing A ♦
113 9316334014 L and R louver Z ♦
114 9316335011 Joint Z ♦
115 9315282019 Spacer D ♦
116 9316219014 Stopper ♦
117 9316374010 Lower cover ♦
118 9316386013 Drain pan cover B ♦
119 9316216013 Damper ♦
120 9316274013 Drain pan cover F ♦
121 9316918009 Fan guard Z ♦
122 9900384074 Step motor (Damper lock R) ♦
123 9900384067 Step motor (Damper lock L) ♦
124 9900424015 Micro switch (Limit) ♦
125 9900384050 Step motor (Damper) ♦
a — Drain pan Z —
3-6. Floor type - (02-91) - 3. Indoor unit parts list
