Item no. Part no. Part name Service part
50 9384904003 S-insulator K ♦
51 9384901002 S-insulator B ♦
52 9900186029 Pressure switch ♦
53 9384894007 4-way valve assy ♦
54 9970194016 Solenoid ♦
55 9384580009 Pipe (Condenser outlet) B ♦
56 9970186073 Expansion valve coil C (L=1160) ♦
57 9970187049 Expansion valve coil B (L=1040) ♦
58 9970186066 Expansion valve coil A (L=920) ♦
59
9384881045 Valve unit (For 18 model) ♦
9384881052 Valve unit (For 24 model) ♦
60 9322436009 Muffler ♦
61 9322477040 3-way valve assy (Ø12.70) ♦
62 9381055029 3-way valve assy (Ø9.52) ♦
63 9384902009 S-insulator F ♦
64 9384903006 S-insulator H ♦
65 9810520005 Compressor ♦
66 9322386007 Cushion rubber ♦
67 9313437008 Special nut ♦
— 9901025020 Thermistor (Valve temperature) A, B ♦
— 9901093012 Thermistor (Valve temperature) C ♦
— 9711839008
Wire with connector
(P131 on Main PCB—P133 on Indicator PCB)
♦
— 9711840004
Wire with connector
(P130 on Main PCB—P132 on Indicator PCB)
♦
— 9711203021
Wire with connector
(P660 on Main PCB—P662 on Inverter PCB)
♦
— 9711841001
Wire with connector
(P100 on Main PCB—P101 on Inverter PCB)
♦
— 9710542015
Wire assy
(P20 on Inverter PCB—Pressure switch)
♦
— 9711747006
Wire with connector
(P70 on Main PCB—Terminal 3 on indoor unit)
♦
— 9707310016
Wire with terminal
(For Terminal 1 [L] on indoor unit)
♦
— 9707310023
Wire with terminal
(For Terminal 2 [N] on indoor unit)
♦
a — Valve bracket —
4-1. Models: AOYG18KBTA3 and AOYG24KBTA3 - (02-95) - 4. Outdoor unit parts list
