Separate wall
Evaporator holder 2 row
32
31
Item no. Part no. Part name Service part
31
9375720254 Evaporator sub assy (For 07 model) ♦
9375720230 Evaporator sub assy (For 09, 12 model) ♦
9375720223 Evaporator sub assy (For 14 model) ♦
9375720247 Evaporator sub assy (For 18 model) ♦
32 9377764065 Insulation box sub assy ♦
3-1. Compact cassette type - (02-7) - 3. Indoor unit parts list
TECHNICAL DATA
AND PARTS LIST
TECHNICAL DATA
AND PARTS LIST
